catalogue

宏微科技半導體產品型錄 2021/2022
功率模組, 分離器件, 晶片

發佈時間: 1月27日, 2021
檔案大小: 7.9 MB
檔案類型: PDF

線上閱讀

下載


catalogue

封裝及線路類型

發佈時間: 1月27日, 2021
檔案大小: 1.49MB
檔案類型: PDF

預覽

下載


catalogue

命名規則

發佈時間: 1月27日, 2021
檔案大小: 82.8 MB
檔案類型: PDF

預覽

下載


規格表

型號 VCES
(V)
IC nom
(A)
VCE (sat)
(V)
Eoff
(mJ)
PD
(W)
RthJC
(℃/W)
封裝 規格表
MM40G3U65BN650401.750.852300.65TO-247IGBT 分離器件
MM120G3T65BM6501201.65.17500.2TO-247PlusIGBT 分離器件
MM50G3U120BMX1200501.952.45350.28TO-247PlusIGBT 分離器件
MM50G3T120BM1200501.83.95350.28TO-247PlusIGBT 分離器件
MM75G3T65B650751.552.524170.36TO-247IGBT 分離器件
MM10G3T120B1200101.850.651251.2TO-247IGBT 分離器件
MM20G3T135B1350201.651.32680.56TO-247IGBT 分離器件
MM60G3U65B650601.81.043000.5TO-247IGBT 分離器件
MM40G3U120BX1200401.923950.38TO-247IGBT 分離器件
MM20G3R135B1350201.61.43330.45TO-247IGBT 分離器件
MM40G3T120B1200401.94.23950.35TO-247IGBT 分離器件
MM25G3T120B1200251.82.43260.46TO-247IGBT 分離器件
MM15G3T120B1200151.851.122000.75TO-247IGBT 分離器件
MM40G3U120B1200401.923950.38TO-247IGBT 分離器件
MM25G3U120BX1200252.1513260.46TO-247IGBT 分離器件
MM40G3U65B650401.750.852300.65TO-247IGBT 分離器件
型號 VRRM
(V)
IF(AV)
(A)
VF
(V)
trr
(ns)
RthJC
(℃/W)
規格表
MM16FU060KC6002x81.8172.5快速恢復二極體分離器件
MM75FU60B600752250.38快速恢復二極體分離器件
MM30FU060P600302200.8快速恢復二極體分離器件
MM15FU60K600152181.3快速恢復二極體分離器件
MM60F120B1200602.1320.45快速恢復二極體分離器件
MM60FU120B1200602.8300.45快速恢復二極體分離器件
MM30FU120B1200302.9260.8快速恢復二極體分離器件
MM30FU120K1200302.9260.8快速恢復二極體分離器件
MM15FU120K1200152.6251.5快速恢復二極體分離器件
MM8FU120K120082.8202快速恢復二極體分離器件
MM30FC120B1200302.8260.8快速恢復二極體分離器件
MM60FC120B1200602.8300.4快速恢復二極體分離器件
MM60FC100B1000602.5300.4快速恢復二極體分離器件
MM30FC100B1000302.65250.8快速恢復二極體分離器件
MM16F70KC7002×81.3192.5快速恢復二極體分離器件
MM15F70K700151.3211.5快速恢復二極體分離器件
MM8F70K70081.3192.5快速恢復二極體分離器件
MM15F060K1600151.3302快速恢復二極體分離器件
MM30FU060B600302220.8快速恢復二極體分離器件
MM30FU60PC6002×152171.6快速恢復二極體分離器件
MM8FU060K60081.8162.8快速恢復二極體分離器件
MM60FU60PC6002×302200.8快速恢復二極體分離器件
MM30FU060K1600302201.5快速恢復二極體分離器件
MM60F060P600601.3400.5快速恢復二極體分離器件
MM60FU060B600602250.5快速恢復二極體分離器件
MM15F060K600151.3231.5快速恢復二極體分離器件
MM30F060B600301.5220.8快速恢復二極體分離器件
MM75F60B600751.35310.38快速恢復二極體分離器件
MM30FU60K600302220.8快速恢復二極體分離器件
MM60F060B600601.3270.5快速恢復二極體分離器件
MM60F060PC6002×301.5220.8快速恢復二極體分離器件
MM30F060PC6002×151.41210.8快速恢復二極體分離器件
MM30F040PC4002×151271.1快速恢復二極體分離器件
MM60F040B400601.15350.48快速恢復二極體分離器件
MM80FU040PC4002×401.3220.8快速恢復二極體分離器件
MM60FU030PC3002×301.2220.8快速恢復二極體分離器件
MM60F020PC2002×300.86220.8快速恢復二極體分離器件
MM100F20B2001001350.24快速恢復二極體分離器件
D92-022002×100.9171.5快速恢復二極體分離器件
型號 VCES
(V)
IC nom
(A)
VCE (sat)
(V)
Ptot
(W)
Eoff
(mJ)
RthJC
(℃/W)
封裝 規格表
MMG400D060B6TC6004001.55120010.70.125GDIGBT 模組
MMG600WB065B6TC6506001.55176023.50.085GWBIGBT 模組
MMG300D060B6TC6003001.5588210.70.17GDIGBT 模組
MMG200Q120UA6TC12002001.8107116.90.14GQIGBT 模組
MMG200D120UA6TC12002001.8107116.40.14GDIGBT 模組
MMG300D120UA6TC12003001.85142824.80.105GDIGBT 模組
MMG400D120UA6TC12004501.85197342.40.076GDIGBT 模組
MMG450D120UA6TC12004501.852142520.07GDIGBT 模組
MMG25H120XB6TC1200251.851572.20.95GHIGBT 模組
MMG50W120XB6TC1200501.82784.10.54GWIGBT 模組
MMG100WD120XB6TC12001001.85159.10.29GWDIGBT 模組
MMG50H120X6TC1200501.827840.54GHIGBT 模組
MMG75H120X6TC1200751.83856.20.39GHIGBT 模組
MMG75W120X6TC1200751.753855.70.39GWIGBT 模組
MMG100W120X6TC12001001.85159.10.29GWIGBT 模組
MMG150W120X6TC12001501.8575013.30.2GWIGBT 模組
MMG25H120XT6TC1200251.851572.20.95GHIGBT 模組
MMG25HD120XT6TC1200251.851662.40.9GHDIGBT 模組
MMG35HD120XT6TC1200351.852083.30.72GHDIGBT 模組
MMG40H120XT6TC1200401.852083.20.72GHIGBT 模組
MMG50HD120XT6TC1200501.8527840.54GHDIGBT 模組
MMG50W120XT6TC1200501.82784.10.54GWIGBT 模組
MMG75W120XT6TC1200751.838570.39GWIGBT 模組
MMG75WD120XT6TC1200751.753855.70.39GWDIGBT 模組
MMG100WD120XT6TC12001001.85159.10.29GWDIGBT 模組
MMG200D170B6TC17002002.21500520.1GDIGBT 模組
MMG300D170B6TC17003002.151760900.085GDIGBT 模組
MMG300WB120B6TC12003001.8159626.30.094GWBIGBT 模組
MMG450WB120B6TC12004501.852305450.065GWBIGBT 模組
MMG600WB120B6TC12006001.93125580.048GWBIGBT 模組
MMG600WB170B6E4N17006001.9537501800.04GWBIGBT 模組
MMG450WE120B6TC12004501.852142360.07GWEIGBT 模組
MMG35CB120X6TC1200351.852143.030.6GCBIGBT 模組
MMG400D120B6BHN12004002.13000220.05GDIGBT 模組
MMG150WJ120XB6TC12001501.8575012.10.2GWIGBT 模組
MMG300D120B6UC12003001.9157823.50.095GDIGBT 模組
MMG100J120U6TC12001001.855158.80.29GJIGBT 模組
MMG200Q120B6TC12002001.8107116.90.14GQIGBT 模組
MMG50S120B6TC1200501.82783.60.54GSIGBT 模組
MMG150J120UZ6TC12001501.8575014.40.2GJIGBT 模組
MMG100J120UZ6TC12001001.855159.10.29GJIGBT 模組
MMG75J120UZ6TC1200751.853846.40.39GJIGBT 模組
MMG50J120UZ6TC1200501.852784.40.54GJIGBT 模組
MMG150S120UA6TC12001501.85750130.2GSIGBT 模組
MMG150S120B6TC12001501.85750130.2GSIGBT 模組
MMG100S120UA6TC12001001.85158.10.29GSIGBT 模組
MMG75S120B6TC1200751.83855.90.39GSIGBT 模組
MMG100S170B6TC17001002.1568122.50.22GSIGBT 模組
MMG200S060B6TC6002001.556005.70.25GSIGBT 模組
MMG100S060B6TC6001001.553302.150.45GSIGBT 模組
MMG75S060B6TC600751.552502.150.6GSIGBT 模組
MMG150D120B6TC12001501.878912.40.19GDIGBT 模組
MMG400D120B6TC12004001.85197342.40.076GDIGBT 模組
MMG450D120B6TC12004501.852142520.07GDIGBT 模組
MMG15CB120X6TC1200151.851301.121.05GCBIGBT 模組
MMG10CB120X6TC1200101.851070.691.25GCBIGBT 模組
MMGT10CB120XB6C1200101.851070.691.25GCBIGBT 模組
MMG15CB120XB6TC1200151.851301.121.05GCBIGBT 模組
MMG10CB120XB6TC1200101.851070.691.25GCBIGBT 模組
MMG200D120B6UC12002002.25107112.30.14GDIGBT 模組
MMG300D120B6TC12003001.851500290.1GDIGBT 模組
MMG200D120B6TC12002001.8107116.40.14GDIGBT 模組
MMG100S120B6TC12001001.75158.30.29GSIGBT 模組
MMGT100J120UZ6C12001001.8557510.50.26GJIGBT 模組
MMG100J120UZ6TN12001001.7450100.28GJIGBT 模組
MMG75J120U6TN1200751.734880.36GJIGBT 模組
MMG75J120UZ6TN1200751.734880.36GJIGBT 模組
MMG150S120B6UC1200150210007.30.15GSIGBT 模組
MMG100S170B17001002.3682240.22GSIGBT 模組
MMG75J120U6TC1200751.83856.30.39GJIGBT 模組
MMG150D170B6TC17001502.151071340.14GDIGBT 模組
MMG100D170B6TC17001002.15789250.19GDIGBT 模組
MMG75S170B6TC1700752.15555170.27GSIGBT 模組
MMG50S170B6TC1700502.05416120.36GSIGBT 模組
MMG400VB065X6TC6504001.55120014.60.125GVBIGBT 模組
MMG75H060XB6EN600751.452503.60.6GHIGBT 模組
MMGT200Q120B6C12002001.751250220.12GQIGBT 模組
MMG150S060B6TC6001501.6544150.34GSIGBT 模組
MMG300Q060B6TC6003001.65882100.17GQIGBT 模組
MMG300B065PD6TC6503001.5588211.20.17GBIGBT 模組
MMG150B065PD6TC6501501.554414.90.34GBIGBT 模組
MMG150CE065PD6TC6501501.653355.10.4GCEIGBT 模組
MMG150D120B6UC12001501.959379.60.16GDIGBT 模組
MMG100S120B6UC12001002.255550.27GSIGBT 模組
MMG75S120B6UC1200752.240540.37GSIGBT 模組
MMG50S120B6UC1200502.23002.20.5GSIGBT 模組
MMG40S120B6UC1200402.1523020.65GSIGBT 模組
MMG450WE065B6EN6504501.451250180.12GWEIGBT 模組
MMG300WB065B6EN6503001.45833120.18GWBIGBT 模組
MMG75WD120XB6TC1200751.853856.20.39GWDIGBT 模組
MMG75W120XB6TC1200751.853856.20.39GWIGBT 模組
MMG40H120XB6TC1200401.952083.350.72GHIGBT 模組
MMG50HD120XB6TC1200501.8527840.54GHDIGBT 模組
MMG35HD120XB6TC1200351.852083.30.72GHDIGBT 模組
MMG25HD120XB6TC1200251.851662.40.9GHDIGBT 模組
MMG600WB170B17006002.737502150.04GWBIGBT 模組
MMG450WB170B17004502.727001500.055GWBIGBT 模組
MMG300WB170B17003002.652000940.075GWBIGBT 模組
MMG300D170B17003002.31875930.08GDIGBT 模組
MMG200D170B17002002.31363560.11GDIGBT 模組
MMG150D170B17001502.31071410.14GDIGBT 模組
MMG100D170B17001002.3789250.19GDIGBT 模組
MMG75S170B1700752.453518.50.28GSIGBT 模組
MMG50S170B1700502.43959.80.38GSIGBT 模組
MMG150WB170H6EN170015021250470.12GWBIGBT 模組
MMG600K170U6EN1700600233001880.045GKIGBT 模組
MMG400K170U6EN1700400227001260.055GKIGBT 模組
MMG600WB170B6EN1700600235701870.04GWBIGBT 模組
MMG450WB170B6EN1700450227001400.055GWBIGBT 模組
MMG300WB170B6EN170030022000940.075GWBIGBT 模組
MMG225WB170B6EN17002252165070.50.09GWBIGBT 模組
MMG400D170B6EN1700400222701260.055GDIGBT 模組
MMG300D170B6EN170030021450940.085GDIGBT 模組
MMG200D170B6EN170020021250630.1GDIGBT 模組
MMG150D170B6EN17001502890470.14GDIGBT 模組
MMG100D170B6EN17001002690310.18GDIGBT 模組
MMG100S170B6EN1700100272032.50.2GSIGBT 模組
MMG75S170B6EN170075262023.50.24GSIGBT 模組
MMG50S170B6EN170050239015.50.38GSIGBT 模組
MMGT100W120X6C12001001.855759.50.26GWIGBT 模組
MMGT75W120X6C1200751.854406.70.34GWIGBT 模組
MMGT50W120X6C1200501.853404.50.44GWIGBT 模組
MMGT75H120X6C1200751.854406.70.34GHIGBT 模組
MMGT50H120X6C1200501.853404.50.44GHIGBT 模組
MMGT100WD120XB6C12001001.855768.50.26GWDIGBT 模組
MMGT75WD120XB6C1200751.854406.20.34GWDIGBT 模組
MMGT75W120XB6C1200751.854406.70.34GWIGBT 模組
MMGT50W120XB6C1200501.853404.50.44GWIGBT 模組
MMGT40H120XB6C1200401.852583.40.58GHIGBT 模組
MMGT25H120XB6C1200251.8519220.78GHIGBT 模組
MMGT15H120XB6C1200151.851361.11.1GHIGBT 模組
MMGT15CB120XB6C1200151.851301.121.05GCBIGBT 模組
MMGTU75J120U1200752.24103.80.3GJIGBT 模組
MMG600WE120B6E4N12006001.75312579.50.048GWEIGBT 模組
MMG600WB120B6E4N12006001.75312579.50.048GWBIGBT 模組
MMG450WB120B6E4N12004501.75230561.50.065GWBIGBT 模組
MMG100W120XB6T4N12001001.755158.50.29GWIGBT 模組
MMG100WD120XB6T4N12001001.755158.50.29GWDIGBT 模組
MMG75WD120XB6T4N1200751.853856.40.39GWDIGBT 模組
MMG50HD120XB6T4N1200501.852804.80.54GHDIGBT 模組
MMG35CE120XB6TC1200351.852142.80.6GCEIGBT 模組
MMG25CE120XB6TC1200251.851762.10.75GCEIGBT 模組
MMG100J120U6T4N12001001.7555590.27GJIGBT 模組
MMG100J120UZ6T4N12001001.7555590.27GJIGBT 模組
MMG150H160UX6TN1200751.734880.36GHIGBT 模組
MMG75W120XB6TN1200751.736880.34GWIGBT 模組
MMG50W120XB6TN1200501.72604.90.48GWIGBT 模組
MMG40W120XB6TN1200401.81954.20.64GWIGBT 模組
MMG40H120XB6TN1200401.81954.20.64GHIGBT 模組
MMG25H120XB6TN1200251.71472.10.85GHIGBT 模組
MMG15H120XB6TN1200151.71051.31.2GHIGBT 模組
MMG15CB120XB6TN1200151.71051.451.15GCBIGBT 模組
MMG150W120X6TN12001501.762514.50.2GWIGBT 模組
MMG100W120X6TN12001001.7450100.28GWIGBT 模組
MMG75W120X6TN1200751.736880.34GWIGBT 模組
MMG75H120X6TN1200751.734880.36GHIGBT 模組
MMG50H120X6TN1200501.72604.90.48GHIGBT 模組
MMG25H120X6TN1200251.71472.10.85GHIGBT 模組
MMG450WB120B6TN12004501.71950550.064GWBIGBT 模組
MMG300WB120B6TN12003001.71400370.09GWBIGBT 模組
MMG225WB120B6TN12002251.71050330.12GWBIGBT 模組
MMG600K120U6TN12006001.72800880.045GKIGBT 模組
MMG400K120U6TN12004001.71925450.065GKIGBT 模組
MMG450D120B6TN12004501.7192055.50.065GDIGBT 模組
MMG400D120UA6TN12004001.71925500.065GDIGBT 模組
MMG400D120B6TN12004001.71925500.065GDIGBT 模組
MMG300D120UA6TN12003001.71450370.085GDIGBT 模組
MMG300D120B6TN12003001.71450370.085GDIGBT 模組
MMG200D120UK6TN12002001.71050250.12GDIGBT 模組
MMG200D120UA6TN12002001.71050250.12GDIGBT 模組
MMG200D120B6TN12002001.71050250.12GDIGBT 模組
MMG200Q120B6TN12002001.71050250.12GQIGBT 模組
MMG150J120UZ6TN12001501.769014.50.18GJIGBT 模組
MMG150D120UA6TN12001501.7780220.16GDIGBT 模組
MMG150D120B6TN12001501.7780220.16GDIGBT 模組
MMG150Q120B6TN12001501.7780220.16GQIGBT 模組
MMG150S120B6TN12001501.762514.50.2GSIGBT 模組
MMG100D120B6TN12001001.7560100.25GDIGBT 模組
MMG100S120B6TN12001001.7450100.28GSIGBT 模組
MMG100S120UK6TN12001001.7450100.28GSIGBT 模組
MMG100S120UA6TN12001001.7450100.28GSIGBT 模組
MMG75S120UA6TN1200751.734880.36GSIGBT 模組
MMG75S120B6TN1200751.734880.36GSIGBT 模組
MMG50S120UA6TN1200501.72604.90.48GSIGBT 模組
MMG50S120B6TN1200501.72604.90.48GSIGBT 模組
MMG100J120UZ6HN12001002.15505.50.27GJIGBT 模組
MMG100J120U6HN12001002.15505.50.27GJIGBT 模組
MMG75J120U6HN1200752.14684.50.32GJIGBT 模組
MMG50H120X6HN1200502.13303.30.45GHIGBT 模組
MMG100HB120H6HN12001002.15505.50.27GHBIGBT 模組
MMG75HB120H6HN1200752.14654.50.32GHBIGBT 模組
MMG50HB120H6HN1200502.130030.5GHBIGBT 模組
MMG40HB120H6HN1200402.12502.50.6GHBIGBT 模組
MMG100H120H6HN12001002.155060.27GHIGBT 模組
MMG75H120H6HN1200752.14654.80.32GHIGBT 模組
MMG50H120H6HN1200502.13003.30.5GHIGBT 模組
MMG800K120U6HN12008002.13950500.038GKIGBT 模組
MMG600K120U6HN12006002.13300370.045GKIGBT 模組
MMG400K120U6HN12004002.12000220.075GKIGBT 模組
MMG300K120U6HN12003002.11650180.09GKIGBT 模組
MMG400D120UK6HN12004002.12100240.07GDIGBT 模組
MMG400D120B6HN12004002.12100240.07GDIGBT 模組
MMG300D120B6HN12003002.1165019.50.09GDIGBT 模組
MMG200D120B6HN12002002.11150120.13GDIGBT 模組
MMG200Q120B6HN12002002.11070120.14GQIGBT 模組
MMG150D120B6HN12001502.18809.60.17GDIGBT 模組
MMG150Q120B6HN12001502.18309.60.18GQIGBT 模組
MMG100D120B6HN12001002.359376.50.16GDIGBT 模組
MMG100S120B6HN12001002.16005.50.25GSIGBT 模組
MMG75S120B6HN1200752.15004.80.32GSIGBT 模組
MMG50S120B6HN1200502.133030.45GSIGBT 模組
MMG100J120UZ12001001.8690100.18GJIGBT 模組
MMG75J120UZ1200751.863070.2GJIGBT 模組
MMG75J120U1200751.863070.2GJIGBT 模組
MMG50J120UZ1200501.84165.50.3GJIGBT 模組
MMG50J120U1200501.84165.50.3GJIGBT 模組
MMG400KR120U12004001.8192543.20.065GKIGBT 模組
MMG600WB065TLB6EN6506001.45176027.50.085GWBIGBT 模組
MMG600WB065TLA6EN6506001.45176027.50.085GWBIGBT 模組
MMG400VB065X6EN6504001.45125014.30.12GVBIGBT 模組
MMG300B065PD6EN6503001.4585611.50.175GBIGBT 模組
MMG200B065PD6EN6502001.456007.10.25GBIGBT 模組
MMG150B065PD6EN6501501.454285.150.35GBIGBT 模組
MMG600WB065B6EN6506001.45176027.50.085GWBIGBT 模組
MMG450WB065B6EN6504501.45125014.50.12GWBIGBT 模組
MMG600WB060DAK6EN6006001.451500250.1GWBIGBT 模組
MMG200W060X6EN6002001.456006.90.25GWIGBT 模組
MMG150W060X6EN6001501.454285.30.35GWIGBT 模組
MMG100W060X6EN6001001.453303.350.45GWIGBT 模組
MMG150W060XB6EN6001501.454285.30.35GWIGBT 模組
MMG100W060XB6EN6001001.453303.350.45GWIGBT 模組
MMG75W060XB6EN600751.452502.80.6GWIGBT 模組
MMG50W060XB6EN600501.451902.10.8GWIGBT 模組
MMG50H060XB6EN600501.451902.10.8GHIGBT 模組
MMG200HB060H6EN6002001.456006.90.25GHBIGBT 模組
MMG150HB060H6EN6001501.454285.30.35GHBIGBT 模組
MMG100HB060H6EN6001001.453303.350.45GHBIGBT 模組
MMG75HB060H6EN600751.452502.80.6GHBIGBT 模組
MMG400HB060B6EN6004001.451250150.12GHBIGBT 模組
MMG300HB060B6EN6003001.45940120.16GHBIGBT 模組
MMG200HB060B6EN6002001.456006.90.25GHBIGBT 模組
MMG150HB060B6EN6001501.454285.30.35GHBIGBT 模組
MMG100HB060B6EN6001001.453303.350.45GHBIGBT 模組
MMG75HB060B6EN600751.452502.80.6GHBIGBT 模組
MMG600WB060B6EN6006001.451578250.095GWBIGBT 模組
MMG450WB060B6EN6004501.45120017.50.125GWBIGBT 模組
MMG800K060U6EN6008001.452100290.07GKIGBT 模組
MMG600K060U6EN6006001.45165022.50.09GKIGBT 模組
MMG800D060B6EN6008001.452100290.07GDIGBT 模組
MMG400D060DE6EN6004001.451250150.12GDIGBT 模組
MMG400D060B6EN6004001.451250150.12GDIGBT 模組
MMG400Q060B6EN6004001.451070150.14GQIGBT 模組
MMG300D060DE6EN6003001.45940120.16GDIGBT 模組
MMG300D060B6EN6003001.45940120.16GDIGBT 模組
MMG300Q060B6EN6003001.45835120.18GQIGBT 模組
MMG200S060DE6EN6002001.456006.90.25GSIGBT 模組
MMG200S060B6EN6002001.456006.90.25GSIGBT 模組
MMG150S060DE6EN6001501.454285.30.35GSIGBT 模組
MMG150S060B6EN6001501.455005.30.3GSIGBT 模組
MMG100S060B6EN6001001.453303.350.45GSIGBT 模組
MMG75S060B6EN600751.452502.80.6GSIGBT 模組
型號 VRRM
(V)
IF(AV)
(A)
VF
(V)
trr
(ns)
PD
(W)
RthJC
(℃/W)
封裝 規格表
MMF400N010DK6B1002X2000.621055200.24FN快速恢復二極體模組
MMF400D120U12004002.119014500.085FD快速恢復二極體模組
MMF400S060DK2B6002X4001.316211360.11FS快速恢復二極體模組
MMF200ZB040DK1D4002X1001.25493380.37FZ快速恢復二極體模組
MMF400N020DK2B2002X2000.91353700.34FN快速恢復二極體模組
MMF200ZB060DK1C6002X1001.21305000.25FZ快速恢復二極體模組
MMF200ZB060DK16002X1001.151056250.2FZ快速恢復二極體模組
MMF400D170B2B17002X4001.95200012500.1FD快速恢復二極體模組
MMF200ZB040DK1C4002X1001.1755600.22FZ快速恢復二極體模組
MMF400D120B2B12002X400318011300.11FD快速恢復二極體模組
MMF300YB070U7003001.3812110400.12FYB快速恢復二極體模組
MMF300Y040DK14002X1501.26512500.1FY快速恢復二極體模組
MMF400Y010DK11002X2001656940.18FY快速恢復二極體模組
MMF200N120DK6B12002X1003.251502800.44FN快速恢復二極體模組
MMF200N120DA6B12002X1003.251502800.44FN快速恢復二極體模組
MMF300S120DA2B12002X3002.81358930.14FS快速恢復二極體模組
MMF300S120B2B12002X3002.81358930.14FS快速恢復二極體模組
MMF150S120DA12002X1501.61455680.22FS快速恢復二極體模組
MMF150S120B2B12002X1501.61455680.22FS快速恢復二極體模組
MMF800Y020DK12002X400116515620.08FY快速恢復二極體模組
MMF400Y040DK1B4002X2001.27515620.08FY快速恢復二極體模組
MMF300Y040DK1B4002X1501.26512500.1FY快速恢復二極體模組
MMF200Y060DK16002X1001.2916250.2FY快速恢復二極體模組
MMF300S120DA12002X3002.81358930.14FS快速恢復二極體模組
MMF300S060DA6002X3001.151508930.14FS快速恢復二極體模組
MMF200S120DA12002X2002.31105680.22FS快速恢復二極體模組
MMF200S060DA6002X2001.151406940.18FS快速恢復二極體模組
MMF150S060DA6002X1501.151305690.22FS快速恢復二極體模組
MMF600S060U6006001.1517516650.075FS快速恢復二極體模組
MMF300S120U12003002.751508900.14FS快速恢復二極體模組
MMF400S120U1200400318011360.11FS快速恢復二極體模組
MMF600S120U12006002.820012500.1FS快速恢復二極體模組
MMF300D170B2B17002X30025008930.14FD快速恢復二極體模組
MMF2X100J120D6B12002X1003.251502800.44FJ快速恢復二極體模組
MMF2X60J120D12002X601.81351920.65FJ快速恢復二極體模組
MMF2X100J120D12002X1002.151253120.4FJ快速恢復二極體模組
MMF2X60J070D7002X601.151502080.6FJ快速恢復二極體模組
MMF2X100J060D6002X1001.35954170.3FJ快速恢復二極體模組
MMF2X100J040D4002X1001.2623600.34FJ快速恢復二極體模組
MMF100S170B2B17002X1001.85005680.22FS快速恢復二極體模組
MMF200S170DA2B17002X2001.87508930.14FS快速恢復二極體模組
MMF300S120DK2B12002X3002.81358930.14FS快速恢復二極體模組
MMF200S120DK2B12002X2002.31105680.22FS快速恢復二極體模組
MMF150S120DK2B12002X1501.61455680.22FS快速恢復二極體模組
MMF300S060DK2B6002X3001.11658350.15FS快速恢復二極體模組
MMF200S060DK2B6002X2001.151406940.18FS快速恢復二極體模組
MMF150S060DK2B6002X1501.25954160.3FS快速恢復二極體模組
MMF400S040DK2B4002X4001.5512012500.1FS快速恢復二極體模組
MMF300YB050U5003001.216011360.11FYB快速恢復二極體模組
MMF400S170U17004001.8110013500.09FS快速恢復二極體模組
MMF300Y060DK1B6002X1501.39516700.075FY快速恢復二極體模組
MMF300Y060DK16002X1501.210015600.08FY快速恢復二極體模組
MMF400Y040DK14002X2001.27515620.08FY快速恢復二極體模組
MMF1000Y010DK11002X5000.8410010410.12FY快速恢復二極體模組
MMF400Z020DK12002X2000.95906250.2FZ快速恢復二極體模組
MMF200ZB040DK1B4002X1001706250.2FZ快速恢復二極體模組
MMF200Y040DK14002X1001706250.1FY快速恢復二極體模組
MMF200ZB040DK14002X1001706250.2FZ快速恢復二極體模組
MMF200N070DA7002X1001.21403700.34FN快速恢復二極體模組
MMF200N120DA12002X1001.771502800.44FN快速恢復二極體模組
MMF100S170DK17002X1001.85005680.22FS快速恢復二極體模組
MMF300S120DK12002X3002.81358930.14FS快速恢復二極體模組
MMF200S120DK12002X2002.31105680.22FS快速恢復二極體模組
MMF150S120DK12002X1501.61455680.22FS快速恢復二極體模組
MMF300S060DK6002X3001.151508930.14FS快速恢復二極體模組
MMF200S060DK6002X2001.151406940.18FS快速恢復二極體模組
MMF150S060DK6002X1501.151305680.22FS快速恢復二極體模組
MMF200N070DK7002X1001.21403700.34FN快速恢復二極體模組
MMF200N120DK12002X1001.771502800.44FN快速恢復二極體模組
MMF300N060DK6B6002X1501.25953700.34FN快速恢復二極體模組
MMF200S170B17002X2001.87508930.14FS快速恢復二極體模組
MMF100S170B17002X1001.85005680.22FS快速恢復二極體模組
MMF300S120B12002X3002.81358930.14FS快速恢復二極體模組
MMF200S120B12002X2002.31105680.22FS快速恢復二極體模組
MMF150S120B12002X1501.61455680.22FS快速恢復二極體模組
MMF300S060B6002X3001.151508930.14FS快速恢復二極體模組
MMF200S060B6002X2001.151406940.18FS快速恢復二極體模組
MMF150S060B6002X1501.151305680.22FS快速恢復二極體模組
MMF100N120B12002X1001.61352800.44FN快速恢復二極體模組
MMF150N060B6B6002X1501.151303700.34FN快速恢復二極體模組
型號 VCES
min.
(V)
IC
TC = 25°C
(A)
RDS(ON)
(Ω)
RthJC
(℃/W)
線路 封裝 規格表
MMN400A010U1 100 400 1.4 0.14 U1 NA
MMN400A006U1 60 568 0.65 0.15 U1 NA
MMN200H010X 100 200 4.50 0.55 X NH MOSFET 模組
MMN668A010U1 100 668 1.10 0.15 U1 NA MOSFET 模組
MMN1000DB010B 100 1250 0.57 0.11 B NDB MOSFET 模組
MMN600DB012B 120 850 0.64 0.10 B NDB icon
MMN600DB015B 150 850 1.20 0.09 B NDB MOSFET 模組
型號 VRRM
(V)
IT(AV)
(A)
VTM
(V)
ITM
(A)
RthJC
(℃/W)
封裝 規格表
MMK90A160UK1600901.62820.35KA晶閘管模組
MMK200S160UA16002001.755000.12KS晶閘管模組
MMK110A160UA16001100.33451.54KA晶閘管模組
MMK90A160UA1600901.62820.35KA晶閘管模組
MMK40A160UA1600401.811410.5KA晶閘管模組
MMK150X030DA3001501.154500.1KX晶閘管模組
MMK35LB160HB1600351.71100.24KLB晶閘管模組
MMK200X040DA4002001.26000.15KX晶閘管模組
MMK200T160UX6J16002001.22000.1KT晶閘管模組
MMK150T160UX6J16001501.181500.18KT晶閘管模組
MMK100U160UX6J16001001.151000.2KU晶閘管模組
MMK75U160UX6J1600751.15750.25KU晶閘管模組
MMK200T160UX16002001.65000.13KT晶閘管模組
MMK150T160UX16001501.654000.16KT晶閘管模組
MMK100T160UX16001001.543140.24KT晶閘管模組
MMK100U160UX16001001.653150.24KU晶閘管模組
MMK75U160UX1600751.52350.35KU晶閘管模組
MMK110A160DK16001101.83450.24KA晶閘管模組
MMK110A160DA16001101.83450.24KA晶閘管模組
MMK200S160B16002001.756000.12KS晶閘管模組
MMK160S160B16001601.545000.18KS晶閘管模組
MMK110A160B16001101.652800.25KA晶閘管模組
MMK90A160B1600901.62820.35KA晶閘管模組
MMK60A160B1600601.541880.45KA晶閘管模組
MMK40A160B1600401.811410.5KA晶閘管模組
型號 VRRM
(V)
IF(AV)
(A)
VF
(V)
IFSM
(A)
RthJC
(℃/W)
封裝 規格表
MMD200S160DK16002001.565000.16DS整流二極體模組
MMD160S160DK16001601.555000.18DS整流二極體模組
MMD110A160DK16001101.625000.3DA整流二極體模組
MMD90A160DK1600901.620000.4DA整流二極體模組
MMD60A160DK1600601.513500.63DA整流二極體模組
MMD400S160U16004001.1120000.09DS整流二極體模組
MMD300S160U16003001.2590000.09DS整流二極體模組
MMD200S160U16002001.565000.16DS整流二極體模組
MMD60A160U1600601.1516000.5DA整流二極體模組
MMD160AB160B16001601.550000.18DAB整流二極體模組
MMD130A180B18001301.535000.2DA整流二極體模組
MMD130A160B16001301.534500.25DA整流二極體模組
MMD110AB160B16001101.423500.3DAB整流二極體模組
MMD240S160B16002401.3100000.14DS整流二極體模組
MMD200S180B18002001.565000.16DS整流二極體模組
MMD200S160B16002001.565000.16DS整流二極體模組
MMD180S180B18001801.560000.18DS整流二極體模組
MMD180S160B16001801.560000.18DS整流二極體模組
MMD160S180B18001601.555000.18DS整流二極體模組
MMD160S160B16001601.555000.18DS整流二極體模組
MMD130S160B16001301.535000.2DS整流二極體模組
MMD110A180B18001101.625000.3DA整流二極體模組
MMD110A160B16001101.625000.3DA整流二極體模組
MMD90A180B1800901.620000.4DA整流二極體模組
MMD90A160B1600901.620000.4DA整流二極體模組
型號 VRRM
(V)
ID
(A)
VF
(V)
IFSM
(A)
RthJC
(℃/W)
封裝 規格表
MMD70EB180X1800702.257000.18DEB三相整流橋模組
MMD200F200X20002001.4520000.09DF三相整流橋模組
MMD160F200X20001601.516000.11DF三相整流橋模組
MMD100F200X20001001.3510000.15DF三相整流橋模組
MMD100E200X20001001.3510000.15DE三相整流橋模組
MMD70E200X2000701.357000.18DE三相整流橋模組
MMD50L160X1600501.45000.2DL三相整流橋模組
MMD70EB160X1600701.357000.18DEB三相整流橋模組
MMD100EB160X16001001.3510000.15DEB三相整流橋模組
MMD250FB180X18002501.5525000.08DFB三相整流橋模組
MMD250FB160X16002501.5525000.08DFB三相整流橋模組
MMD200FB160X16002001.4520000.09DFB三相整流橋模組
MMD150FB160X16001501.4515000.11DFB三相整流橋模組
MMD250F180X18002501.5525000.08DF三相整流橋模組
MMD250F160X16002501.5525000.08DF三相整流橋模組
MMD200F180X18002001.4520000.09DF三相整流橋模組
MMD200F160X16002001.4520000.09DF三相整流橋模組
MMD150F180X18001501.4515000.11DF三相整流橋模組
MMD150F160X16001501.4515000.11DF三相整流橋模組
MMD100E180X18001001.3510000.15DE三相整流橋模組
MMD100E160X16001001.3510000.15DE三相整流橋模組
MMD70E180X1800701.357000.18DE三相整流橋模組
MMD70E160X1600701.357000.18DE三相整流橋模組

您專業的功率半導體供應團隊
